Download Backwall Template
Total visual area: Panel A: 35.3“w x 82.54”h Panel B: 23.49”w x 70.73”h
Panel C (backlit): 47.125”w x 94.375”h
Panel D (double sided pillowcase): 151.68”w x 17.71”h
Top (outside D): 61.93”w x 17.71”h
Top (inside D): 60.722”w x 17.71”h
Side 1 (outside D): 90”w x 17.71”h Side 2 (inside D): 88.891”w x 17.71”h
*We recommend that the inside be a pattern or solid color. Please consider obstructions and spaces created by the extrusions when designing graphics. Be sure to include a 2” bleed around the perimeter of panel B.
Medium monitor bracket holds 26-40” LCD, max weight: 50 lbs / 22.68 kgs
Max counter weight = 50 lbs / 22.68 kgs
*LCD monitor not included *Foreground counter not included in purchased/ rental kit
Fabric material: Dye-sublimated fabric and UV printed on 6mm white Sintra
